How do I connect my launch monitor to my network?

The only launch monitor that can be connected through your network (Wi-Fi or hard-wired to router) is the EYE MINI launch monitor; all other launch monitors are designed explicitly to connect to the Uneekor software via the PC's onboard Ethernet port.

EYE MINI - Hardwired Network Setup

To set up the EYE MINI for use with your PC through a router, network switch, or wall jack connection, please follow these steps:

  1. Navigate to the EYE MINI Settings
  2. On Page 3 of the Settings, set Ethernet to Dynamic
  3. Set Wi-Fi to Station(Client)
  4. Connect the EYE MINI to your router, network switch, or wall jack via Ethernet cable
  5. Open the Uneekor Launcher management software
  6. Navigate to the Install Wizard in the Uneekor Launcher management software
  7. Tick Dynamic ethernet connection mode, then click Continue
  8. Click Register to your account for the EYE MINI under the list of connected devices. Note that you may need to click Refresh once or twice for it to appear in the list
  9. Click Select on the same EYE MINI, then click Continue
  10. Click Select keys for current device
  11. Untick the REFINE license key with a duration of 1 month, unless you want to begin your free 1-month REFINE trial immediately. You can always activate this later
  12. Tick/Untick any other license keys that you do/do not want activated at this time on this computer, then click Activate
  13. After receiving the "Activation completed!" message, click Continue
  14. On the EYE MINI, enter PLAY mode, and place a ball down in front of it. Once the EYE MINI says "Ready", you should see the Uneekor Launcher management software say "Ready to swing"
  15. Take a test shot. If it goes through on the EYE MINI, you should see that a ball launch was detected in the Uneekor Launcher management software, along with the ball speed
  16. Click Continue when you have finished taking test shots
  17. Click Continue once more to be taken to the Start page, where you can now install the software you activated


If the EYE MINI shows up as a connected launch monitor after following all of the above steps, then congratulations, your EYE MINI is now configured for use on your PC! Test out some shots in VIEW to make sure it's working as expected.

EYE MINI - Wi-Fi Network Setup

Ensure that the EYE MINI is connected to the same Wi-Fi network as the PC that you want to connect to by following these steps:

    1. Connect the EYE MINI to either your PC, or your router / wall jack / network switch via Ethernet cable
    2. Navigate to the EYE MINI Settings
    3. On Page 3 of the Settings, set Ethernet to Static if connected directly to PC, otherwise set to Dynamic
    4. Set Wi-Fi to Station(Client)
    5. Press BACK on the EYE MINI to save your changes
    6. Open the Uneekor Launcher management software
    7. Navigate to the Start page
    8. Navigate to the launch monitor Settings (within this page)
    9. Click Refresh within the launch monitor settings, then wait for it to detect nearby Wi-Fi networks
    10. Connect to the Wi-Fi network that your PC is connected to
    11. Disconnect the Ethernet cable from the EYE MINI
    12. Click Refresh in the top-right to confirm if the EYE MINI is detected over Wi-Fi
